Acemagic S3A R7 5700U
Description
xSpecification (5700U)
xProcessor
AMD Ryzen™ 9 5700U Processor, 8 Cores/16 Threads
( 8MB L3 Cache, base frequency 1.8GHz, turbo frequency up to 4.3GHz)
Graphics
AMD Radeon RX Vega 8 or AMD Radeon™ Graphics
(Graphics frequency: 1900MHz, Graphics cores: 8)
Memory
32GB: 2x16GB DDR4 2666MHz Dual Channel (SO-DIMM Slots×2, up to 64GB,The maximum frequency supported by the memory slot is DDR5 3200MHz)
BAREBONE : Without RAM and hard disk
Storage
1TB: 1TB M.2 2280 SATA SSD (2 x M.2 2280 Slots, 1 x M.2 2280 Slot supports NVMe PCle3.0 SSD or SATA SSD, 1 x M.2 2280 Slot only supports SATA SSD, single hard disk interface supports up to 2TB SSD)
Wireless Connectivity
WiFi 6 + BT5.2
Video Output
HDMI 2.0(4K@60Hz)×1
USB3.2 Gen2 Type-C (4K@60Hz) ×1
DP1.4 (4K@60Hz)×1
Audio Output
HDMI 2.0(4K@60Hz)×1
USB3.2 Gen2 Type-C (4K@60Hz) ×1
DP1.4 (4K@120Hz)×1
3.5mm Audio Jack ×1
Ports & Buttons
10/100/1000Mbps adaptive RJ45 Gigabit Ethernet Port × 1
USB3.2 Gen2 Type-A Port × 2 (10Gbps, front interface)
USB3.2 Gen1 Type-A Port × 4 (5Gpbs, rear interface)
USB3.2 Type-C (Support DP1.4, 4K@60Hz, maximum 10Gbps data transfer) ×1
DC IN × 1
HDMI 2.0 ×1
DP1.4 ×1
3.5mm Audio Jack ×1
Power Button x1
Power
DC 19V/3.42A, DC Header 5.5*2.1mm
System
Windows 11 Pro
Dimensions
128*128*41.3mm
Specification （6900HX）
xAcemagic S3A R9 6900HX
Processor
AMD Ryzen™ 9 6900HX Processor, 8 Cores/16 Threads
(16MB L3 Cache, base frequency 3.3GHz, turbo frequency up to 4.9GHz)
Graphics
AMD Radeon™ 890M ( Graphics card frequency: 2400MHz, graphics card core number: 12)
Memory
32GB: 2x16GB DDR5 4800MHz Dual Channel (SO-DIMM Slots×2, up to 64GB,The maximum frequency supported by the memory slot is DDR5 4800MHz)
BAREBONE : Without RAM and hard disk
Storage
1TB: 1TB M.2 2280 NVMe PCle 3.0×4 SSD (2*M.2 2280 Slots, 2 hard disk interfaces support M.2 NVMe PCle3.0/4.0 SSD, do not support SATA SSD, up to 4TB)
Wireless Connectivity
WiFi 6 + BT5.2
Video Output
HDMI 2.0(4K@60Hz)×1
USB3.2 Gen2 Type-C (4K@60Hz) ×1
DP2.0 (4K@60Hz)×1
Audio Output
HDMI 2.0(4K@60Hz)×1
USB3.2 Gen2 Type-C (4K@60Hz) ×1
DP2.0 (4K@60Hz)×1
3.5mm Audio Jack ×1
Ports & Buttons
10/100/1000Mbps/2.5Gbps自适应 RJ45 Gigabit Ethernet Port ×1
USB3.2 Gen2 Type-A Port × 2 (10Gbps, front interface)
USB3.2 Gen1 Type-A Port × 4 (5Gpbs, rear interface)
USB3.2 Type-C (Support DP1.4, 4K@60Hz, maximum 10Gbps data transfer) ×1
DC IN × 1
HDMI 2.0 ×1
DP2.0×1
3.5mm Audio Jack ×1
Power Button x1
Power
DC 19V/3.42A, DC Header 5.5*2.1mm
System
Windows 11 Pro
Dimensions
128*128*41.3mm
